NOT MEASUREMENT SENSITIVE
MIL-DTL-2/38E
25 September 2002
SUPERSEDING
MIL-DTL-2/38D
9 June 1995
DETAIL SPECIFICATION SHEET
VALVE, CYLINDER, GAS:
NITROUS OXIDE, OUTLET 910 (PIN-INDEX), MEDICAL
(PRESSURES THROUGH 3000 psig (20680 kPa) AT 120 ºF (48.9 ºC))
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-2 listed in that issue of the Department of Defense Index of
Specifications and Standards (DoDISS) specified in the solicitation.
REQUIREMENTS:
TYPE DESIGNATION: V38-910-4
TABLE I. Valve requirements.
PRD1
Style
Class
Composition
Inlet
Outlet
Handwheel
size
application
I
30
D
4
910
No
1
1
Pressure Relief Device
SPECIAL REQUIREMENTS:
1. The valve components shall be chromium plated.
2. Mark the valve body: NITROUS OXIDE MED.
OPTIONAL REQUIREMENTS:
1. Wrench or key (required) (not required).
AMSC N/A
1 of 2
FSC 8120
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
