INCH-POUND
MIL-DTL-17376/1A
22 March 2007
SUPERSEDING
MIL-C-17376/1
14 September 1973
DETAIL SPECIFICATION SHEET
CAPS AND FLANGES, COMPRESSED-GAS CYLINDER: CAPS
Reactivated after 22 March 2007 and may be used for new
and existing designs and acquisitions.
This detail specification sheet is approved for use by all departments and agencies of the
Department of Defense.
The requirements for acquiring the product described herein shall consist of this detail
specification sheet and MIL-DTL-17376, "Caps and Flanges, Compressed-Gas Cylinder,
General Specification for".
REQUIREMENTS: The compressed-gas cylinder cap shall be as specified herein and in
accordance with figure 1.
1. Material. Steel shall conform to ASTM A 109/A 109M, "Standard Specification
for Steel, Strip, Carbon, (0.25 Maximum Percent), Cold-Rolled", temper 3, 4 or 5,
ASTM A 1008/A 1008M, "Standard Specification for Steel, Sheet, Cold-Rolled, Carbon,
Structural, High-Strength Low-Alloy, High-Strength Low-Alloy with Improved Formability,
Solution hardened, and Bake Hardened", or ASTM A 1011/A 1011M, "Standard Specification
for Steel, Sheet and Strip, Hot-Rolled, Carbon, Structural, High-Strength Low-Alloy, High-
Strength Low-Alloy with Improved Formability, and Ultra-High Strength". Malleable iron shall
conform to ASTM A 47/A 47M, "Standard Specification for Ferritic Malleable Iron Castings",
grade 32510.
AMSC N/A
FSC 8120
