NOT MEASUREMENT SENSITIVE
MIL-DTL-2/18D
25 September 2002
SUPERSEDING
MIL-DTL-2/18C
9 June 1995
DETAIL SPECIFICATION SHEET
VALVE, CYLINDER, GAS: CARBON MONOXIDE, OUTLET 350
(PRESSURES THROUGH 3000 psig (20680 kPa) AT 120 ºF (48.9 ºC))
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-2 listed in that issue of the Department of Defense Index
of Specifications and Standards (DoDISS) specified in the solicitation.
REQUIREMENTS:
TYPE DESIGNATION: V18-350-2
TABLE I. Valve requirements.
PRD1
Style
Class
Composition
Inlet
Outlet
Handwheel
size
application
III
30
A
6
350
Yes
5
1
Pressure Relief Device
SPECIAL REQUIREMENTS:
1. Mark the valve body: CARBON MONOXIDE.
2. A valve outlet cap shall be provided.
INTENDED USE: The valves covered by this specification sheet are intended for use with
carbon monoxide cylinders.
AMSC N/A
1 of 2
FSC 8120
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
