NOT MEASUREMENT SENSITIVE
MIL-DTL-2/57A
25 September 2002
SUPERSEDING
MIL-DTL-2/57
9 June 1995
DETAIL SPECIFICATION SHEET
VALVE, CYLINDER, GAS:
HELIUM AND NITROGEN (INERT-OIL TOLERANT), OUTLET 621
(PRESSURES 3001 THROUGH 5500 psig (20690 THROUGH 37900 kPa) AT 120 ºF (48.9 ºC))
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-2 listed in that issue of the Department of Defense Index of
Specifications and Standards (DoDISS) specified in the solicitation.
REQUIREMENTS:
TYPE DESIGNATION
CYLINDER SERVICE
TYPE PRESSURE
PRESSURE psig
RELIEF DEVICE (PRD)
V57-621-8
3500 through 3600
1
V57-621-10
4000
1
V57-621-11
4500
1
TABLE I. Valve requirements.
Style
Class
Composition
Inlet
Outlet
Handwheel
PRD
size
application
III
55
A
6
621
Yes
1
AMSC N/A
1 of 2
FSC 8120
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
