NOT MEASUREMENT SENSITIVE
MIL-DTL-2/64A
25 September 2002
SUPERSEDING
MIL-DTL-2/64
9 June 1995
DETAIL SPECIFICATION SHEET
VALVE, CYLINDER, GAS: HYDROGEN CHLORIDE, OUTLET 330
(PRESSURES THROUGH 3000 psig (20680 kPa) AT 120 ºF (48.9 ºC))
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-2 listed in that issue of the Department of Defense Index of
Specifications and Standards (DoDISS) specified in the solicitation.
REQUIREMENTS:
TYPE DESIGNATION: V64-330-2
TABLE I. Valve requirements.
PRD1
Style
Class
Composition
Inlet
Outlet
Handwheel
size
application
I
30
C
6
330
No
4
B2
IV
30
6
330
Yes
4
1
Pressure Relief Device
2
Must be stainless steel.
SPECIAL REQUIREMENTS:
1. Mark the valve body: HYDROGEN CHLORIDE.
OPTIONAL REQUIREMENTS:
1. Outlet cap or plug (required) (not required).
AMSC N/A
1 of 2
FSC 8120
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
