NOT MEASUREMENT SENSITIVE
MIL-DTL-2/70A
25 September 2002
SUPERSEDING
MIL-DTL-2/70
9 June 1995
DETAIL SPECIFICATION SHEET
VALVE, CYLINDER, GAS:
HIGH PRESSURE, FLAMMABLE OR TOXIC MIXTURES, OUTLET 350
(PRESSURES THROUGH 3000 psig (20680 kPa) AT 120 ºF (48.9 ºC))
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-2 listed in that issue of the Department of Defense Index of
Specifications and Standards (DoDISS) specified in the solicitation.
REQUIREMENTS:
TYPE DESIGNATION: V70-350-2
TABLE I. Valve requirements.
PRD1
Style
Class
Composition
Inlet
Outlet
Handwheel
size
application
III
30
A
6
350
Yes
5
IV
30
A
6
350
Yes
5
1
See intended use.
SPECIAL REQUIREMENTS:
1. Mark the valve body: H.P., FLAMMABLE OR TOXIC MIXT.
OPTIONAL REQUIREMENTS:
1. Outlet cap or plug (required) (not required).
2. Pressure relief device (PRD) (required) (not required).
AMSC N/A
1 of 2
FSC 8120
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
