NOT MEASUREMENT SENSITIVE
MIL-DTL-2/8D
25 September 2002
SUPERSEDING
MIL-DTL-2/8C
9 June 1995
DETAIL SPECIFICATION SHEET
VALVE, CYLINDER, GAS: ANHYDROUS AMMONIA
(CONVEX-HEAD CYLINDER), OUTLET 240, INLET 0.75 INCH
(PRESSURES UP THROUGH 500 psig (3450 kPa) AT 70 ºF (21.1 ºC))
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-2 listed in that issue of the Department of Defense Index of
Specifications and Standards (DoDISS) specified in the solicitation.
REQUIREMENTS:
TYPE DESIGNATION: V8-240-0
TABLE I. Valve requirements.
PRD1
Style
Class
Composition
Inlet
Outlet
Handwheel
size
application
I
05
B
6
240
No
0
1
Pressure Relief Device
SPECIAL REQUIREMENTS:
1. Unless otherwise specified, the valve shall be supplied with a dip tube for 15.00-inch
diameter cylinders.
2. The valve seat shall be tin.
3. Mark the valve body: AMMONIA S.
AMSC N/A
1 of 2
FSC 8120
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
