MIL-DTL-17376/3B
NOTES:
1. Part or identification number (PIN) to be used for high pressure flanges acquired to
this detail specification is created as follows:
`1 17376/3 X
M
Size: 1 = C17376/3-1 (3-1/8 UNS-1) high pressure flange
Specification sheet number
General specification number
M prefix
A
3-1/8"-11 UNS-1
3-16"
30°
11/16" MIN.
5/32"
2-25/32" DIA. MAX.
Size
Part number
Dimension A
1
C17376/3-1
3-1/8-11 UNS-1
NOTE:
1. All dimensions are in inches.
FIGURE 1. Flange.
