NOT MEASUREMENT SENSITIVE
MIL-DTL-2/24D
25 September 2002
SUPERSEDING
MIL-DTL-2/24C
9 June 1995
DETAIL SPECIFICATION SHEET
VALVE, CYLINDER, GAS: ETHYLENE OXIDE, OUTLET 510
(PRESSURES THROUGH 500 psig (3450 kPa) AT 70 ºF (21.1 ºC))
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-2 listed in that issue of the Department of Defense Index of
Specifications and Standards (DoDISS) specified in the solicitation.
REQUIREMENTS:
TYPE DESIGNATION: V24-510-1
TABLE I. Valve requirements.
PRD1
Style
Class
Composition
Inlet
Outlet
Handwheel
size
application
I
05
B
6
510
No
2
1
Pressure Relief Device
SPECIAL REQUIREMENTS:
1. Dip tube shall be in accordance with MIL-DTL-2.
2. Mark the valve body: ETHYLENE OXIDE S.
AMSC N/A
1 of 2
FSC 8120
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
