INCH-POUND
MIL-DTL-3701F
7 June 2010
SUPERSEDING
MIL-DTL-3701E
20 April 2009
DETAIL SPECIFICATION
CYLINDERS, COMPRESSED GAS: DOT-8 AND DOT-8AL
ACETYLENE, WITH VALVES
This specification is approved for use by all Departments and Agencies of the
Department of Defense.
1. SCOPE
1.1 Scope. This specification covers new steel cylinders, with applicable valves and caps,
intended for acetylene service.
1.2 Classification. The cylinders covered by this specification are of the capacities shown
in table I, as specified (see 6.2).
TABLE I. Physical characteristics.
Dimensions
Capacity
Valve
(in inches)
(in cubic
Flange
Cap
(specification
feet (ft³))
Inlet threads
specification
specification
A-A-59860)
OD
Height
10
4.0 ±0.5
12.5 ±1.0
3/818NGT
N/A
N/A
AA59860-005
40
6.0 ±0.5
20.0 ±1.0
3/818NGT
N/A
N/A
AA59860-006
AA59860-0032
1
75
7.0 ±0.5
26.0 ±1.0 111 1/2-NGT
MIL-C-17376/2
MIL-C-17376/1
AA59860-0043
AA59860-0032
1
190
9.5 ±0.5
32.5 ±1.0 111 1/2-NGT
MIL-C-17376/2
MIL-C-17376/1
AA59860-0043
Comments, suggestions, or questions on this document should be addressed to Defense Supply
Center Richmond, ATTN: DSCR-VEB, 8000 Jefferson Davis Highway, Richmond, VA 23297-
5616 or e-mailed to STDZNMGT@dla.mil. Since contact information can change, you may
want to verify the currency of this address information using the ASSIST database at
https://assist.daps.dla.mil/.
AMSC N/A
FSC 8120
