MIL-DTL-3701F
TABLE I. Physical characteristics - Continued.
Capacity
Dimensions
Valve
(in cubic
Flange
Cap
(in inches)
(specification
feet (ft³))
Inlet threads
specification
specification
A-A-59860)
OD
Height
AA59860-0032
1
225
12.0 ±0.5 29.0 ±1.0 111 1/2-NGT
MIL-C-17376/2
MIL-C-17376/1
AA59860-0043
AA59860-0032
1
360
12.0 ±0.5 41.0 ±1.0 111 1/2-NGT
MIL-C-17376/2
MIL-C-17376/1
AA59860-0043
1
Optionally, 3/414NGT inlet threads may be specified (see 6.2). When specifying this optional inlet, use valves
AA59860-001 and AA59860-002, in place of AA59860-003 and AA59860-004 respectively.
2
When a compression packed valve is required, specify AA59860-003 or -001 (see 6.2).
3
When an O-ring valve is required, specify AA59860-004 or -002 (see 6.2).
1.3 Part or identifying number (PIN). The PIN to be used for cylinders acquired to this
specification is created as follows:
M 3701 - XXX
Example of reference part number: M3701 - 010
Size: cylinder capacity in cubic feet (see table I)
Specification number
Prefix for military specification
M3701 - 010 indicates a 10 ft3 capacity cylinder, with an outer diameter of 4.0 inches
±0.5 inch, a height of 12.5 inches ±1.0 inch, 3/818NGT inlet threads, and a valve specified
as AA59860-005.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this
specification. This section does not include documents cited in other sections of this specification
or recommended for additional information or as examples. While every effort has been made to
ensure the completeness of this list, document users are cautioned that they must meet all specified
requirements of the documents cited in sections 3 and 4 of this specification, whether or not they
are listed.
2.2 Government documents.
2.2.1 Specifications and standards. The following specifications and standards form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of
these documents are those cited in the solicitation or contract.
2
