MIL-DTL-22606D(SH)
1.3 Part or identifying number (PIN).
M22606 - XXXX - XXXX -
X
- XX.X - XXX - XXX
Drain plug type: S Straight plug
R Right angle plug
Y "Y" plug
M Separator inlet/outlet plug
D Internal drain plug (see figure 7)
X Special plug
Drain plug seal: R O-ring seal
W Seal welded
Inlet plug type: S Straight plug
R Right angle plug
Y "Y" plug
M Separator inlet/outlet plug
X Special plug
Inlet plug seal:
R O-ring seal
W Seal welded
Inlet plug size:
Capacity: Minimum capacity in cubic feet (see table I)
Service: A Compressed air
B Oxygen
C Oil free nitrogen, helium, or helium-
oxygen mixtures
Class:
3000 3000 psi MAWP
5000 5000 psi MAWP
5500 5500 psi MAWP
Type/subtype: GF General service flask, straight
design
GFSW General service flask, straight
design, skirted, wide diameter
CD General service flask, curved
design
CDA General service flask, curved
design, special attachments
SF Air moisture separator flask
Specification number
Example PIN: M22606-GF-3000-A-8.0-SR1-SW3
3
